SS304 V type coffee powder mixer / Ground coffee mixing machine / Grinded coffee powder mixing machine

FOB Reference Price:Get Latest Price
US $1,000-8,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Mixer Type:
Agitator
Product Type:
Fertilizer
Application:
Powder
Additional Capabilities:
Other
Place of Origin:
Henan, China (Mainland)
Brand Name:
DY
Model Number:
DY-0.5
Max. Loading Capacity:
500L
Voltage:
220V 380V
Power(W):
2.2KW
Dimension(L*W*H):
2*1.65*0.7M
Certification:
CE ISO
Warranty:
12 Months
After-sales Service Provided:
Engineers available to service machinery overseas
v shape mixer material:
SS304
Mixing Drum thickness:
3mm
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
Export wooden packing
Port
qingdao , Shanghai
Lead Time :
7days

Specifications

V type coffee powder mixer
1:Directly manufacture
2:SS 304
3: 100-3000L
4:use in food medical , chemical ,indust

                                       V type coffee powder mixer



 V type coffee powder mixer      Food , chemical , medicine , Feed, Metallurgy area , ect




 V type coffee powder mixer  V shape blender  is composted by two welded v shape drum , and these two drum are asymmetric for the shaft . Because of the Rotary motion , powder/ small pellet are continuously separated and combined alternately repeatedly in the inclined drum ,  and move from one drum to another ,  at the same time , Material will overlapping in space when slipping and will spreaded in new place , and this process will be done again and again to get good mixing result .





 V type coffee powder mixer

Model: DY-0.5

  • l  Capacity : 0.5m3
  • l  Max Volume : 200L
  • l  Discharge hole size : 150mm
  • l  Rotary hight : 2250mm
  • l  Drum speed : 9r/min
  • l  Power: 1.5kw
  • l  Machine size : 2300*700*2100mm

Model : DY-0.3

  • l  Total Volume : 0.3M3 /300L
  • l  Max Volume : 120L (40%)
  • l  Discharge Hole size: 150mm
  • l  Motor power: 2.2kw
  • l  Drum Spee: 9-12r/min
  • l  Rotary height : 2000mm
  • l  Machine size: 2000*1650*700mm
  • l  Weight : 400kg







V mixing machine .jpgAUTO FILLING .jpg





                 V shape mixer  can  feeding automatically or manual



mixing part .jpg





                        Electric element are Delix Brand



V mixing machine detail .jpg
